connected to a separate UPS system (in a two-UPS environment, the primary input cable must be supported by an online UPS similar to
Tripp Lite SmartOnline)
Advanced ATS configurations using separate mains circuits, backup generators and out of phase utility feeds are fully supported
On-board processor evaluates power quality on both inputs to prevent transfer to the secondary source when unavailable or of lower quality
than the primary source
2-7 millisecond transfer time between primary and secondary inputs
DHCP/Manual configuration support; Supports HTTP, HTTPS, PowerAlert Network Management System, SMTP, SNMPv1, SNMPv2,
Telnet, SSH, FTP, DHCP, BOOTP, NTP protocols
Compatible with optional ENVIROSENSE temperature monitor
Outlets are factory programmed for sequential turn-on at 250 millisecond intervals as the PDU is first energized
Front panel LEDs confirm power availability on primary / secondary inputs and each output receptacle
TAA Compliant Version Available - Order Tripp Lite PDUMH20ATNETAA
Specifications
OVERVIEW
PDU Type
OUTPUT
Output Capacity
Details
Frequency
compatibility
Output VA
Output nominal
voltage
Outlet quantity / type
Outlet Type
Customized load
management
receptacles
INPUT
PDU Input Voltage
Maximum Input
Amps (A)
Maximum Input
Amps (A) Details
PDU Plug Type
Input cord length
details
Phase
Auto-Transfer Switch; Switched
1.9kW (120V input), 2.0kW (127V input), 1.6kW (100V input); 20A maximum (Agency de-rated to 16A continuous)
60 Hz
2400
100-127V nominal, single phase
16 NEMA 5-15/20R
NEMA 5-15R, NEMA 5-20R
16 individually controlled load management receptacles
100; 120; 127
20
Agency de-rated to 16A continuous
NEMA 5-20P; NEMA L5-20P
Both input cables are 12 ft / 3.6m - the cables each terminate to a L5-20P locking plug on the input side. Two
included 6 inch plug adapters convert the locking plugs to NEMA 5-20P plugs
Single-Phase
LEDS ALARMS & SWITCHES
Front panel LEDs
16 front panel LEDs display power on - off status for each outlet, plus 2 LEDs for power status on each input line
cord. Digital current meter display shows the amount of power consumption in amps for entire output of PDU.
PHYSICAL
Shipping
Dimensions (HWD/in)
Shipping
Dimensions
(HWD/cm)
6.25 x 22.5 x 23.5
15.9 x 57.2 x 59.7
